Tenda i9 User Manual

32

None
It allows any wireless client to connect to a wireless network. This option is not
recommended because it affects network security.

WEP
Parameter description
Parameter
Description
Authentication Type
It specifies the encryption type for the WEP security mode of the AP. The options
include Open, Shared, and 802.1x.
The options share the same encryption process.

Open
It specifies that authentication is not required and data exchanged is encrypted
using WEP. In this case, a wireless client can connect to the wireless network
corresponding to the selected SSID without being authenticated, and the data
exchanged between the client and the network is encrypted in WEP security mode.

Shared
It specifies that a shared key is used for authentication and data exchanged is
encrypted using WEP. In this case, a wireless client must use a preset WEP key to
connect to the wireless network corresponding to the selected SSID. The wireless
client can be connected to the wireless network only if they use the same WEP key.

802.1x
It specifies that 802.1x authentication is required and data exchanged is encrypted
using WEP. In this case, ports are enabled for user authentication when valid
clients connect to the wireless network corresponding to the selected SSID, and
disabled when invalid users connect to the wireless network.
Default Key
It specifies the default WEP key for the Open and Shared encryption types.
For example, if Default Key is set to Key 2, a wireless client can connect to the

Tenda i9 Specifications

General

5 GHz	No
2.4 GHz	Yes
Bandwidth	24 GHz
Channel bandwidth	533 MHz
Transmitting power	20 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	-
Placement	Ceiling, Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	System
Output current	1 A
Output voltage	12 V
Power consumption (max)	8 W
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	4
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antennas quantity	2
Antenna gain level (max)	2 dBi
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	184 mm
Height	38 mm
