Step 3 Set the router 2 functioned as VPN client.
1. To access the page, choose VPN > PPTP/L2TP Client.
2. PPTP/L2TP Client: Click Enable.
3. Client Type: Click PPTP.
4. WAN: Select the WAN port used by router 2 for the VPN client, which is WAN1 in this example.
5. Server IP Address/Domain Name: Enter the IP address (or corresponding domain name) of the WAN
port used by the VPN server.
6. Username/Password: Enter the username and password of the VPN client assigned by the VPN server.
7. Encryption: Click Enable.
8. Remote LAN: Enter the local network segment of the server.
9. Remote Subnet Mask: Enter the local network subnet mask of the server.
10. Click OK.
