Parameter
Description
IP Address
It specifies the IP address assigned to a client.
IPSec SA
Name
It specifies the name of an IPSec tunnel.
SPI
It specifies the SPI parameter. The outgoing SPI of the IPSec tunnel should
be same as the incoming SPI of its peer device. The ingoing SPI of the IPSec
tunnel should be same as the outgoing ISP of its peer device.
Direction
It specifies the data transmission direction ingoing and outgoing of the
IPSec tunnel.
Tunnel
It specifies the transmission direction of IPSec tunnel data over the
internet.
Data Flow
It specifies the transmission direction of IPSec tunnel data on the LAN
network.
Security Protocol
It specifies the security protocol used by the IPSec tunnel.
AH Verification
Algorithm
It specifies the AH verification algorithm used by the IPSec tunnel.
ESP Verification
Algorithm
It specifies the ESP verification algorithm used by the IPSec tunnel.
ESP Encryption
Algorithm
It specifies the ESP encryption algorithm used by the IPSec tunnel.
16.3 Traffic Statistics
To access the page, choose System Status > Traffic Statistics.
This module enables you to view the current traffic statistics information of the WAN port of the router, and the
clients connected to the router. The dynamic chart displays the upload and download traffic information of the
current WAN port of the router, while the list details the information of a single client.
