Introduction
1
2 Introduction
2.1 General
The MIDAS micro 2883 is the smallest, most compact insulation tester on the market. It is designed for power /
dissipation factor and capacitance testing in the field and in the factory.
2.2 Scope of Supply
The following items are supplied with a standard single channel system:
Qty Part No. Description
1 4842957 Midas micro unit
1 4843122 Manual Midas micro
1 0781811 Memory Stick
1 4843112 Accessories Bag
The accessories consist in the following items:
1 4843309 Bag
2 0781721 Cable Drums for HV and Measuring cables
1 4843042 Cable high voltage 20m
1 4842635 Measuring Cable blue 20m
1 4842636 Measuring Cable white 20m
1 4842637 Measuring Cable yellow 20m
3 4843107 Measuring Cable clamp
2 0781769 Connection wire
2 0780069 Connection clip
1 4843125 Earthing Cable with clamp 20m
1 4843440 High voltage clamp
1 4842106 Extension clamp
2 4843453 Bushing Adapter BNC
1 4843455 Bushing Adapter HV
1 4843115 Handheld with cable 10m
1 0781758 Copper wire 25m / 0.8mm diameter
1 0781631 ODU Connector
1 0780999 Bend protection ODU
2 0781256 Spare Paper Roll for Thermal Printer
