Setup
65
12.3 Settings Tab
Some of the measurement settings not available in Basic Mode
The Settings tab
12.3.1 Measurement settings
HV Off after measurement
Normally checked. Automatically turns off the high voltage
in manual mode when a valid and stable measurement
value has been recorded. Deselect if the high voltage
should not be switched off after a measurement recording.
Advanced Measurement Display
Select if the advanced measurement values are selectable
or if the selection is limited to the most common values.
Limiting the number of measurement values makes it
easier to find a specific one.
Print on Record
Prints the measurement values on-the-go, i.e. every newly
recorded value is added to the printout.
Service Dump on USB
Saves real data on USB memory stick. Used for service
purposes only.
Excitation Mode
Activates the special mode for excitation current
measurements. In this mode the regulation and stability
criteria will be based on the measured current and not on
the voltage and dissipation factor. This allows to measure
higher currents at low voltages and to get faster results
than in normal mode. In excitation mode noise
suppression isn’t available. Do not use this mode for
normal C/DF measurements.
