Operation Elements
23
7 Operation Elements
7.1 Front-Panel Features
1 Ground Terminal / Earthing
2 Ventilation Slots
3 High Voltage Output
4 Emergency Stop Button
5 Low Voltage Point V
6 Measuring Input HV GND
7 Measuring Input A
8 Measuring Input B
9 Safety Switch Input
10 External Warning Lamp Output
11 Warning Lamp
12 Temperature Sensor Input
13 USB Port
14 Ethernet Port
15 Display with Touch panel
16 Printer
17 Socket for mains cable
18 Box for mains fuses
19 Power Switch
