11.1.7 The File Menu
The internal file system of the Midas micro 2883 is an XML structure. If a
measuring data transfer to the USB stick is performed the data are always
exported in two formats: XML and CSV.
Due to clarity reasons only the XML files are visualized in the file list structures to
keep the interface simple.
New File
Creates a new, empty file.
Load File
Loads an existing file from the internal storage.
Save File
Saves the current file on the internal storage.
Save File As
Saves the current file under a new name.
Delete File
Allows deleting any measurement file on the internal storage.
USB Transfer
Allows transferring files from or to an external USB Drive. Opens up a
transfer dialog window.
USB Transfer
File transfer dialog
