5.9 Parallel & Series Equivalent Circuits
The MIDAS micro 2883 measures the parallel equivalent circuit values.
The following formulas describe the calculation of the value conversion parallel – series :
Parallel equivalent circuit C
p
-R
p
**tan
1
Cp
Rp
⋅⋅
=
δω
* measured values
Series equivalent circuit C
s
-R
s
Cs Cp= ⋅ +* ( tan *)1
2
δ
Rs Rp= ⋅
+
tan *
tan *
2
2
1
δ
δ
* measured values
