Calibration Interval
2 years recommended
Interfaces
Display 7” TFT , 800 x 480, Colour Touch Screen
Measurement
Inputs
3 x BNC
USB 1 x USB 2.0
Ethernet/LAN 1 x RJ-45
Safety Features
Open Ground Detection
Security Handheld Switch, Foot Switch
Warning Lamp
Audible Warning Signal on High-Voltage ON
Measured Values
DF (tan δ) DF (tan δ)
@20°C
DF%(tan δ) DF%(tan δ)
@20°C
PF (cos ϕ) PF (cos ϕ)
@20°C
PF%(cos ϕ) PF%(cos ϕ)
@20°C
Capacitance Cx Resistance Rx Inductance Lx Frequency f
Test Current Ix Mains frequency fm Noise frequency fn Apparent Power S
Real Power P Reactive Power Q S/N Ratio Quality Factor QF
Ref Current In Capacitance Cn Current Imag (Lp) Current Ife (Rp)
Phase-angle ϕ (Zx)
Voltage U
RMS
Insulation Temp. Temp. Corr. Factor K
Conditions Comments Connection mode Time/Date
Settings
Standards
Safety IEC 61010-1 (2010) EN 61010-1:2001(ZEK 01.4-08)
EMC EN 61000-3-2 (2006) EN 61000-3-3 (2008) EN 61000-4-2 (2009)
EN 61000-4-3 (2010) EN 61000-4-4 (2004) EN 61000-4-5 (2006)
EN 61000-4-6 (2007) EN 61000-4-11(2004) EN 55011 +A1(2009)
Drop Test IEC 60068-2-31 Edition 4.0 (face, corner, free fall)
Shock & Vibration IEC 60068-2-6 IEC 60068-2-64 Edition 2.0 IEC 60068-2-27
Ageing MIL-T-28800
Physical and Environmental Specifications
Mains Supply 90 .. 264 VAC 50/60 Hz, 800 W, active PFC (acc. IEC61000-3-2)
Protecting Fuse T 10 A
Connection Fused IEC-320 connector
Operating Temperature -10 ... +50°C (14 .. 122 °F)
Storage Temperature -20 … +70°C (-4 .. 158 °F)
Relative Humidity 5 ... 95 %, non-condensing
Dimensions (W x D x H) 54.6 x 34.7 x 24.7 cm (21.5” x 13.66” x 9.72”)
Weight Unit 24.9 kg (55 lb)
Weight Accessories Bag 16 kg (35.7 lb)
