Measuring Information
Information about the measurement which is about to
be performed. Voltage, test mode and frequency are
indicated.
Warnings and Errors
The warnings and errors indicate why the
measurement cannot start. As a result the HV on
button will be greyed out as long as a warning is
present.
Interlock open
Handheld / Footswitch is not pressed.
Emergency Button
Emergency button has been pressed. Release
Emergency button by turning it in the indicated
direction.
HV supply overheated
If maximum output current is sourced for a long period
the internal HV source may heat up. In order to protect
the device from damage the Midas micro 2883 comes
with an overheat protection. Please wait until the HV
source has cooled down and retry.
HV GND not connected
The HV GND measuring probe is not connected to
ground. Make sure the HV GND probe is connected to
ground and that the device is properly grounded.
Unsafe HV cable shield
This is an error condition. If the internal connection of
the high voltage ground is broken no safe
measurement is possible. Please do not further use
the instrument and contact support@tettex.com
HV On Button
Press HV On to initiate test.
Back Button
Go back to instruction screen
Home Button
Go back to home screen
