USB Transfer
File transfer dialog
Copy Files to
Allows copying files from the MIDAS micro 2883 to the external USB Drive (arrow
to the right) or from the USB Drive to the instrument (arrow to the left).
Select files either in the file list to the left (contents of 2883 storage) or to the right
(contents of USB Drive) then click on the corresponding arrow button.
Add Folder
Allows adding a new folder on the external USB Drive
Go to higher level folder
Click here to go one level up in the folder hierarchy.
Select File type
Allows selecting which type of file is displayed in the file lists. Measurement files
(xml or csv) and Image Files (bmp) are possible selections.
Images can be used in self-defined sequences. See chapter 11.2.1 Setting up a
Sequence.
