Texecom Premier Elite 24

UDL & Digi Options Premier Elite 24,24-W, 48,48-W, 88, 168 & 640 Installation Manual
106 INS176-9
Tamper Fault ID ***
Panel ID is transmitted as follows:
Device
ID
Panel 000
Keypad ID is transmitted as follows:
Network
RKP
1
2
3
4
5
6
7
8
1 11 21 31 41 51 61 71 81
2 12 22 32 42 52 62 72 82
3 13 23 33 43 53 63 73 83
4 14 24 34 44 54 64 74 84
5 15 25 35 45 55 65 75 85
6 16 26 36 46 56 66 76 86
7 17 27 37 47 57 67 77 87
8 18 28 38 48 58 68 78 88
Expander ID is transmitted as follows:
Network
EXP
1
2
3
4
5
6
7
8
1 11 21 31 41 51 61 71 81
2 12 22 32 42 52 62 72 82
3 13 23 33 43 53 63 73 83
4 14 24 34 44 54 64 74 84
5 15 25 35 45 55 65 75 85
6 16 26 36 46 56 66 76 86
7 17 27 37 47 57 67 77 87
8 18 28 38 48 58 68 78 88
ATS Path Fault ID ***
Line Fault ID is transmitted as follows:
Device
ID
Panel 00
RedCARE 01
Com 300/Com 2400 02
Com IP 002
Expander ID is transmitted as follows:
Network
EXP
1
2
3
4
5
6
7
8
1 11 21 31 41 51 61 71 81
2 12 22 32 42 52 62 72 82
3 13 23 33 43 53 63 73 83
4 14 24 34 44 54 64 74 84
5 15 25 35 45 55 65 75 85
6 16 26 36 46 56 66 76 86
7 17 27 37 47 57 67 77 87
8 18 28 38 48 58 68 78 88
Reset ID ****
Reset ID is transmitted as follows:
Device
ID
Panel (RR) 00
Engineer 01
Anti-Code 02
RedCARE 03
Keyswitch 04
User 05
Wintex 07
Expander ID is transmitted as follows:
Network
EXP
1
2
3
4
5
6
7
8
1 11 21 31 41 51 61 71 81
2 12 22 32 42 52 62 72 82
3 13 23 33 43 53 63 73 83
4 14 24 34 44 54 64 74 84
5 15 25 35 45 55 65 75 85
6 16 26 36 46 56 66 76 86
7 17 27 37 47 57 67 77 87
8 18 28 38 48 58 68 78 88
Power Fault ID ****
Reset ID is transmitted as follows:
Device
ID
Bell Under Voltage 00
Digi Under Voltage 01
System Under Voltage 02
Aux Under Voltage 03
Battery Under Voltage 04
Network 1 Under Voltage 05
Network 2 Under Voltage* 06
Network 3 Under Voltage** 07
Network 4 Under Voltage** 08
Network 5 Under Voltage** 09
Network 6 Under Voltage** 10
Network 7 Under Voltage** 11
Network 8 Under Voltage** 12
*168 & 640 Only
**640 Only
