Texecom Premier Elite 24

System Overview Premier Elite 24,24-W, 48,48-W, 88, 168 & 640 Installation Manual
6 INS176-9
Keys
ICONS UK English English
B
=

=
B
C
=
C
=
C
s
=

=
s
A
=
A
=
A
R
=
R
=
R
N
=
N
=
N
y
=
y
=
y

=
y
=
y
n
=
n
=
n
LED's
=
Power = Ready
=
Armed/Info
OK
= Ready
=
Omit = Service
Zone Expanders
8XP
• 8 fully programmable DP or EOL zones
• 8 fully programmable outputs (100mA -ve applied each)
• Speaker output
• Programmable auxiliary input
• Remotely wired
60iXD
• 2 loops x 30 fully programmable iD zones
• iD biscuit technology
• Plug-on
“iD” is a registered trade mark of Chloride Safety System Limited.
Output Expanders
OP16
• 16 fully programmable outputs (100mA each)
• 1 fault output (100mA -ve applied)
• Can be connected to mimic panels to give zone indication
• Can be connected to relays and sounders
RM8 Relay Module
• Plug-on relay card (RedCARE footprint)
• 8 separate inputs for standalone operation
• 8 x 3Amp relay outputs (n/o, n/c, com)
• Output ‘ON’ LED indication
Communicators
Com300
• Multi-protocol communicator supporting Fast Format, Contact
ID, SIA Level II and EasyCom Pager protocols
• 300-baud modem for remote uploading and downloading using
the Wintex UDL software and a PC
• For use with an analogue telephone line (REN = 1)
Com2400
• Multi-protocol communicator supporting Fast Format, Contact
ID, SIA Level II and EasyCom Pager and SMS Messaging
protocols
• 2400-baud modem for remote uploading and downloading
using the Wintex UDL software and a PC
• Sends SMS text messages to mobile phones
• For use with an analogue telephone line (REN = 1)
ComIP
• Multi-protocol communicator supporting Fast Format, Contact ID
and SIA Level II protocols via TCP/IP
• High speed modem for remote uploading and downloading using
the Wintex UDL software and a PC
• For use with ADSL/DSL/Broadband/WAN/LAN etc.
ComGSM
• Provides a GSM telephone path for Com300 & Com2400 Digital
Communicators
• Sends SMS text messages to mobile phones
• Arm, Disarm, Reset the alarm, turn outputs on and off, omit
zones and send messages to the control panel using SMS text
messages
• 9600-baud modem for remote uploading and downloading
using the Wintex UDL software and a PC
Other Devices
PC-Com
• For connecting a PC to the control panel via an RS232 Serial
port allowing local uploading and downloading using Wintex
UDL software
USB-Com
• For connecting a PC to the control panel via a USB 1.0 or 2.0
port allowing local uploading and downloading using Wintex
UDL software
PRINT-Com
• For connecting a serial printer to the control panel
Memory Module (not 640)
 Fits onto the expansion port to provide a 10,000 event log.
Battery Splitter
 Allows two backup batteries to be connected to a single set of
battery terminals, and will provide appropriate monitoring and
charging for each.
External Sounders
 Texecom supply a range of external sounders
