Premier Elite 24,24-W, 48,48-W, 88, 168 & 640 Installation Manual System Outputs
INS176-9 81
70 – Confirmed PA
If an area is in PA alarm this output type activates when one of the
following happens.
 another PA zone is activated
 A tamper is detected from a different device
 A second signal from a multi action PA
 A global tamper within the timer period
71 – Confirmed Intruder
If an area is in Alarm, this output type activates when a different zone
(not the entry route) is activated in the same area. This output type
deactivates at the end of the ‘confirmation time’ when a valid code is
entered within the Abort time, or when the alarm is reset.
Output Group - Zone
Any zone can be assigned to this output type. Select a zone number.then
select an output type from the following options:
Mimic
This output type activates when the selected zone is activated and
deactivates when the zone is secure. This output will work if the zone
is armed or disarmed.
MimicArm
This output type activates when the selected zone is activated and
deactivates when the zone is secured. This output will only work if the
zone is armed.
Alarm
This output type activates when the selected zone causes an alarm
and deactivates when the alarm is reset. This output will only work if
the zone is armed.
Tamper
This output type activates when the selected zone causes a Tamper
alarm and deactivates when the tamper is reset. This output will work
if the zone is armed or disarmed.
MimicLat
This output type activates when the selected zone is activated and
deactivates when the next time the zone is activated. This output will
work if the zone is armed or disarmed.
Omitted
This output type activates when the selected zone is omitted and
deactivates when the zone is reinstated.
Output Group - User Code Entered
Any user can be assigned to this output type.
This output type activates for 5 seconds when the selected User
code is entered.
Output Group - Control Timer
Select a Control Timer.
These output types activate when the respective control timer turns
on and deactivate when the timer turns off.
Output Group - PC Control
Select a PC Control.
These output types can be activated and deactivated using a PC
running the Wintex UDL software.
Output Group - Door Control
Select a Door Control from 1,1 to 1,4 (48), 1,1 to 1,8 (88), 1,1 to 2,8
(168) 1,1 to 8-8 (640).
These output types activate for the duration of the ‘Door Strike’ timer
when a valid User code (assigned to the same door) is entered and
deactivates when the timer expires.
These output types are used in conjunction with the ‘Door Control’
User option (see page 111 for details).
Output Attributes
Assigning an attribute to an output will alter how the output works.
The following attributes can be assigned to any of the various types
listed.
Select attributes by pressing keys 1 to 8 (a letter on the display
means the attribute is selected, a ‘Dot’ on the display means the
attribute is not selected).
U - User Test
The output will activate when a user performs a User test (see page
117 for details).
I - Inverted
The output is inverted (an output that applies 0V when active will
become an output that applies 12V when active).
L - Latching
When activated, the output will remain on until a valid User code is
entered.
1 - Use Pulse Period 1
When activated, the output will remain on for the duration of the
‘Pulse Period 1’ timer (see page 62 for details).
2 - Use Pulse Period 2
When activated, the output will remain on for the duration of the
‘Pulse Period 2’ timer (see page 62 for details).
3 - Use Pulse Period 3
When activated, the output will remain on for the duration of the
‘Pulse Period 3’ timer (see page 62 for details).
C - Only Active With Custom Output 1 Stage A
The output will only operate whilst ‘Custom Output Stage A’ is ‘On’
(see page ‘Custom Outputs’ for details).
R - Random
The output will activate randomly. A minimum and maximum ‘On’
time can also be programmed (see page 62 for details).
X-10 Outputs
X-10 Outputs are outputs that can be configured to operate devices
that are connected to an X-10 controller. These outputs can be
assigned a house and unit number.
To Program an output for X-10, proceed as follows:
Program the output type to ensure correct operation when the
programmed condition occurs i.e. an output programmed as
‘Entry/Exit’ will activate when the selected area is in the entry or exit
mode and deactivate when the area is no longer in the entry or exit
mode.
Assign any attributes i.e. ‘Pulsed 1’ would cause the output to be
timed for the duration of the ‘Pulse 1’ timer.
Assign a House and Unit number i.e. this is the physical address of
the X-10 Unit and ensures that the correct unit in the correct area
operates when the output condition is met i.e the correct unit
switches on and off during Entry/Exit.
