Texecom Premier Elite 24

Premier Elite 24,24-W, 48,48-W, 88, 168 & 640 Installation Manual Installation
INS176-9 29
Zone and Output Numbering 24/48/88/168
Expander Zones Keypad Zones
Address
Zones
(Network 1)
Zones
(Network 2)
Address
Zones
Network 1
Zones
Network 2
1 9 - 16 73 - 80 1
Unmapped Unmapped
2 17 - 24 81 - 88 2
Unmapped Unmapped
3 25 - 32 89 - 96 3
Unmapped Unmapped
4 33 - 40 97 - 104 4
Unmapped Unmapped
5 41 - 48 105 - 112 5 Unmapped Unmapped
6 49 - 56 113 - 120 6 Unmapped Unmapped
7 57 - 64 121 - 128 7 Unmapped Unmapped
8 65 - 72 129 - 136 8 Unmapped Unmapped
Keypad Zones
Address
Zones
Network 1
Zones
Network 2
Zones
Network 3
Zones
Network 4
Zones
Network 5
Zones
Network 6
Zones
Network 7
Zones
Network 8
1 Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped
2 Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped
3 Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped
4 Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped
5
Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped
6
Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped
7
Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped
8
Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped
Expander/OP16 Outputs
Address
Outputs
Network 1
Outputs
Network 2
Outputs
Network 3
Outputs
Network 4
Outputs
Network 5
Outputs
Network 6
Outputs
Network 7
Outputs
Network 8
1 Exp. 1, 1-8 Exp. 1, 1-8 Exp. 1, 1-8 Exp. 1, 1-8 Exp. 1, 1-8 Exp. 1, 1-8 Exp. 1, 1-8 Exp. 1, 1-8
2 Exp. 2, 1-8 Exp. 2, 1-8 Exp. 2, 1-8 Exp. 2, 1-8 Exp. 2, 1-8 Exp. 2, 1-8 Exp. 2, 1-8 Exp. 2, 1-8
3 Exp. 3, 1-8 Exp. 3, 1-8 Exp. 3, 1-8 Exp. 3, 1-8 Exp. 3, 1-8 Exp. 3, 1-8 Exp. 3, 1-8 Exp. 3, 1-8
4 Exp. 4, 1-8 Exp. 4, 1-8 Exp. 4, 1-8 Exp. 4, 1-8 Exp. 4, 1-8 Exp. 4, 1-8 Exp. 4, 1-8 Exp. 4, 1-8
5
Exp. 5, 1-8 Exp. 5, 1-8 Exp. 5, 1-8 Exp. 5, 1-8 Exp. 5, 1-8 Exp. 5, 1-8 Exp. 5, 1-8 Exp. 5, 1-8
6
Exp. 6, 1-8 Exp. 6, 1-8 Exp. 6, 1-8 Exp. 6, 1-8 Exp. 6, 1-8 Exp. 6, 1-8 Exp. 6, 1-8 Exp. 6, 1-8
7
Exp. 7, 1-8 Exp. 7, 1-8 Exp. 7, 1-8 Exp. 7, 1-8 Exp. 7, 1-8 Exp. 7, 1-8 Exp. 7, 1-8 Exp. 7, 1-8
8
Exp. 8, 1-8 Exp. 8, 1-8 Exp. 8, 1-8 Exp. 8, 1-8 Exp. 8, 1-8 Exp. 8, 1-8 Exp. 8, 1-8 Exp. 8, 1-8
