Texecom Premier Elite 24

Installation Premier Elite 24,24-W, 48,48-W, 88, 168 & 640 Installation Manual
18 INS176-9
Power Supply Ratings
If installing to EN50131 or PD6662, the system standby times in the event of a mains power failure vary depending on the grade and how AC fail is
signalled:
 When calculating the current consumption of the system you must include the current taken by the control panel and all the devices that it
powers. If the total current exceeds the “Rated Output” for the grade you are installing to then an additional power supply is required
Premier Elite 24 (Metal)
Current
Current Consumption 95mA
Maximum Current Available
0.75A charge 1.0A
0.3A charge 1.9A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h 24h 30h 60h
1 x 7Ah
0.3A 0.48A 0.19A 0.13A 0.021A
1 x 17Ah
0.3A 1.32A 0.61A 0.47A 0.18A
0.75A 1.0A 0.61A 0.47A 0.18A
Standby and Recharge Times
EN50131-1 Grade 1 Grade 2 Grade 3
Minimum Standby
Period
12h 12h 30h *
Maximum Recharge
Time
72 Hrs
72 Hrs
24 Hrs
PD6662 Grade 1 Grade 2 Grade 3
Standby Period 12 Hrs 12 Hrs 24 Hrs **
Maximum Recharge
Time
72 Hrs 72 Hrs 24 Hrs
*30h if MAINS FAIL is reported to ARC, otherwise 60h
**This time may be halved if mains failure is signalled to an ARC
Jumper Settings
Battery
Arrangement
Recharge
Time
Battery Charge Selector
1 x 7Ah < 24Hrs 0.3 A
1 x 17Ah
< 24Hrs 0.75 A
< 72Hrs 0.3 A
Premier Elite 24 (Polymer)
Current
Current Consumption 95mA
Maximum Current Available
0.3A charge
1.1A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h
1 x 7Ah 0.3A 0.48A
Standby and Recharge Times
EN50131-1 Grade 1 Grade 2
Minimum Standby Period 12h 12h
Maximum Recharge Time 72 Hrs 72 Hrs
PD6662 Grade 1 Grade 2
Standby Period 12 Hrs 12 Hrs
Maximum Recharge Time 72 Hrs 72 Hrs
Premier Elite 48/88/168
Current
Current Consumption 125mA
Maximum Current Available
0.75A charge 1.0A
0.3A charge 1.9A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h 24h 30h 60h
1 x 7Ah 0.3A 0.458A 0.166A 0.108A
1 x 17Ah
0.3A 1.29A 0.583A 0.441A 0.158A
0.75A 1.0A 0.583A 0.441A 0.1588A
Standby and Recharge Times
EN50131-1 Grade 1 Grade 2 Grade 3
Minimum Standby
Period
12h 12h 30h *
Maximum Recharge
Time
72 Hrs 72 Hrs 24 Hrs
PD6662 Grade 1 Grade 2 Grade 3
Standby Period 12 Hrs 12 Hrs 24 Hrs **
Maximum Recharge
Time
72 Hrs 72 Hrs 24 Hrs
*30h if MAINS FAIL is reported to ARC, otherwise 60h
**This time may be halved if mains failure is signalled to an ARC
Jumper Settings
Battery
Arrangement
Recharge
Time
Battery Charge Selector
1 x 7Ah < 24Hrs 0.3 A
1 x 17Ah
< 24Hrs 0.75 A
< 72Hrs 0.3 A
Premier Elite 640
Current
Current Consumption 125mA
Maximum Current Available
0.75A charge 1.0A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h 24h 30h 60h
1 x 17Ah 0.75A 1.0A 0.558A 0.416A 0.133A
Standby and Recharge Times
EN50131-1 Grade 1 Grade 2 Grade 3
Minimum Standby
Period
12h 12h 30h *
Maximum Recharge
Time
72 Hrs 72 Hrs 24 Hrs
PD6662 Grade 1 Grade 2 Grade 3
Standby Period 12 Hrs 12 Hrs 24 Hrs **
Maximum Recharge
Time
72 Hrs 72 Hrs 24 Hrs
*30h if MAINS FAIL is reported to ARC, otherwise 60h
**This time may be halved if mains failure is signalled to an ARC
Premier Elite 24-W & 48-W
Current
Current Consumption 150mA
Maximum Current Available
0.3A charge 1.0A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h
1 x 7Ah 0.3A 0.433A
Standby and Recharge Times
EN50131-1 Grade 1 Grade 2
Minimum Standby Period 12h 12h
Maximum Recharge Time 72 Hrs 72 Hrs
PD6662 Grade 1 Grade 2
Standby Period 12 Hrs 12 Hrs
Maximum Recharge Time 72 Hrs 72 Hrs
