Texecom Premier Elite 24

Installation Premier Elite 24,24-W, 48,48-W, 88, 168 & 640 Installation Manual
30 INS176-9
Zone and Output Numbering 640
Expander Zones
Address
Zones
Network 1
Zones
Network 2
Zones
Network 3
Zones
Network 4
Zones
Network 5
Zones
Network 6
Zones
Network 7
Zones
Network 8
1 1 - 8 65 - 72 129 - 136 193 - 200 257 - 264 321 - 328 385 - 392 449 - 456
2 9 - 16 73 - 80 137 - 144 201 - 208 265 - 272 329 - 336 393 - 400 457 - 464
3 17 - 24 81 - 88 145 - 152 209 - 216 273 - 280 337 - 344 401 - 408 465 - 472
4 25 - 32 89 - 96 153 - 160 217 - 224 281 - 288 345 - 352 409 - 416 473 - 480
5
33 - 40
97 - 104 161 - 168 225 - 232 289 - 296 353 - 360 417 - 424 481 - 488
6
41 - 48
105 - 112 169 - 176 233 - 240 297 - 304 361 - 368 425 - 432 489 - 496
7
49 - 56
113 - 120 177 - 184 241 - 248 305 - 312 369 - 376 433 - 440 497 - 504
8
57 - 64
121 - 128 185 - 192 249 - 256 313 - 320 377 - 384 441 - 448 505 - 512
Keypad Zones
Address
Zones
Network 1
Zones
Network 2
Zones
Network 3
Zones
Network 4
Zones
Network 5
Zones
Network 6
Zones
Network 7
Zones
Network 8
1 Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped
2 Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped
3 Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped
4 Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped
5
Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped
6
Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped
7
Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped
8
Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped Unmapped
Expander/OP16 Outputs
Address
Outputs
Network 1
Outputs
Network 2
Outputs
Network 3
Outputs
Network 4
Outputs
Network 5
Outputs
Network 6
Outputs
Network 7
Outputs
Network 8
1 Exp. 1, 1-8 Exp. 1, 1-8 Exp. 1, 1-8 Exp. 1, 1-8 Exp. 1, 1-8 Exp. 1, 1-8 Exp. 1, 1-8 Exp. 1, 1-8
2 Exp. 2, 1-8 Exp. 2, 1-8 Exp. 2, 1-8 Exp. 2, 1-8 Exp. 2, 1-8 Exp. 2, 1-8 Exp. 2, 1-8 Exp. 2, 1-8
3 Exp. 3, 1-8 Exp. 3, 1-8 Exp. 3, 1-8 Exp. 3, 1-8 Exp. 3, 1-8 Exp. 3, 1-8 Exp. 3, 1-8 Exp. 3, 1-8
4 Exp. 4, 1-8 Exp. 4, 1-8 Exp. 4, 1-8 Exp. 4, 1-8 Exp. 4, 1-8 Exp. 4, 1-8 Exp. 4, 1-8 Exp. 4, 1-8
5
Exp. 5, 1-8 Exp. 5, 1-8 Exp. 5, 1-8 Exp. 5, 1-8 Exp. 5, 1-8 Exp. 5, 1-8 Exp. 5, 1-8 Exp. 5, 1-8
6
Exp. 6, 1-8 Exp. 6, 1-8 Exp. 6, 1-8 Exp. 6, 1-8 Exp. 6, 1-8 Exp. 6, 1-8 Exp. 6, 1-8 Exp. 6, 1-8
7
Exp. 7, 1-8 Exp. 7, 1-8 Exp. 7, 1-8 Exp. 7, 1-8 Exp. 7, 1-8 Exp. 7, 1-8 Exp. 7, 1-8 Exp. 7, 1-8
8
Exp. 8, 1-8 Exp. 8, 1-8 Exp. 8, 1-8 Exp. 8, 1-8 Exp. 8, 1-8 Exp. 8, 1-8 Exp. 8, 1-8 Exp. 8, 1-8
