Texecom Premier Elite 24

Premier Elite 24,24-W, 48,48-W, 88, 168 & 640 Installation Manual Installation
INS176-9 39
Premier 48/88/168/640 & Premier Elite 24/48/88/168/640 SMS Control Commands
Operation Command Example
Arm System ???? arm [areas][s]
“5678 arm s” = arm all areas and report
back status.
Part Arm System ???? parm (1/2/3)[s]
“5678 parm 1” = part arm 1 all areas (no
status)
Disarm System ???? darm [areas][s]
“5678 darm abcs” = disarm areas abc and
report back status.
Reset System ???? reset [areas] “5678 reset” = reset all areas
Omit Zone(s) ???? omit (zones) “5678 omit 1 5 12” = omit zones 1, 5 and 12
Unomit Zone(s) ???? uomit (zones) “5678 uomit 12” = reinstate zone 12
Turn Outputs On
???? op on
(outputs)[s]
“5678 op on 134” = turn PC outputs 1, 3
and 4 on.
Turn Outputs Off
???? op off
(outputs)[s]
“5678 op off 4s” = turn PC output 4 off and
report back status.
Pulse Outputs On
???? op on (outputs)
[p]
“5678 op on p” = pulse PC output 2 on.
Pulse Outputs Off
???? op off (outputs)
[p]
“5678 op off p” = pulse PC output 2 off.
Send Message ???? mess (message)
“5678 mess How Are You” = Displays How
Are You on all keypads.
System Status ???? status
“5678 status” =
Armed: (1 - 8 or A - P)
Alarm: (1 - 8 or A - P)
Output: (1 - 8)
Mains: (OK or Fault)
Battery: (OK or Fault)
Phone Line: (OK or Fault)
Output Status ???? status O
“5678 status O” =
Armed: (1 - 8 or A - P)
Alarm: (A - P)
Channels: (1 - 8)
Digi: (1 - 8)
Panel: (1 - 5)
Mains: (OK or Fault)
Battery: (OK or Fault)
Phone Line: (OK or Fault)
GSM/Radio-Pad
Status
???? status R
“5678 status R” =
Serial: ####### (only if Radio-Pad
fitted)
NUA: ###### (only if Radio-Pad
fitted)
FSS: ### (only if Radio-Pad fitted)
RSS: ### (only if Radio-Pad fitted)
BER: ### (only if Radio-Pad fitted)
CRC: ### (only if Radio-Pad fitted)
GSM-Signal: ###
GSM-BER: ###
What will be sent in the Text Message
The following information will be received in the text message:
Alarm Reporting & Upload/Download via IP
IP Mode (panel port programmed as ComIP, fixed
IP SIM card)
1. Enter “Engineers Programming” mode and select “UDL/Digi
Options”, then select “Com Port Setup”. Ensure Com Port is
programmed as “ComIP”. Leave the IP address, port &
gateway blank.
2. Now select the “Digi Options” menu and make sure that
“Digi Option 1” is programmed for “Digi is Enabled”.
3. Now select “Program Digi” and ensure the following options
are programmed for one of the ARC options:
a) Protocol:Program as required.
b) Account No: Program as required
c) Dialling Attempts: Program as required.
d) Report Areas: Program as required.
e) Reports: Program as required.
f) Config.: Program as required.
g) Protocol Options : Program as required.
h) For Upload/Download via Wintex edit the Account/Panel
Details and fill in the IP address you have been given and
Port number.
All three status LED’s should now be on, if status LED 3 is dim, this
indicates a low GSM signal level. If the signal level is low, try moving
the antenna to improve the reception.
3 Western Road
12:45.58 01/12
Zone 003 Alarm
The Detector in
the Lounge
Area: A.......
My Home
Up to 16 chara c ters of text (this is the Printer Header)
Time and Date
E v e n t T y p e
Zone/User name text
Area that caused the event
Name programmed into phone
