Texecom Premier Elite 24

Specifications Premier Elite 24,24-W, 48,48-W, 88, 168 & 640 Installation Manual
128 INS176-9
Remote Keypads
Electrical
Operating Voltage 10 - 13.7VDC
ACE Type B
Current Consumption without Prox
Quiescent (Not Backlit)
Alarm (Not Backlit)
Fully Backlit
Alarm + Fully Backlit
25mA
45mA
100mA
145mA
Current Consumption with Prox
Quiescent (Not Backlit)
Alarm (Not Backlit)
Fully Backlit
Alarm + Fully Backlit
85mA
105mA
185mA
205mA
Data Network 4-wire standard 7/0.2 alarm cable
up to 500m Star, Daisy Chain or
any combination of the two
Keypad Type
LCD
LCDL
LCDP
LCDLP
32 Character LCD
32 Character large LCD
LCD + Prox Reader
LCDL + Prox Reader
Zones 2
EOL Resistor Values
EOL Resistor
Contact Resistor
Fault Resistor
0 - 1k
1k1 to 4k
4k1 to 5k6
5k7 to 8k
8k1 to 20k (30k)
21k+ (30k+)
(Alternatives Available)
2k2 (3k3)
4k7 (3k3)
2k2
Zone Short
Zone Secure
Zone Fault
Zone Active
Zone Mask
Zone Tamper
Output
100mA switched to 0V
Back Lighting Fully adjustable
Speaker Output (LCDL/LCDLP)
Minimum load 8Ω
Speaker Volume (LCDL/LCDLP)
Fully adjustable
Proximity Reader (LCDP/LCDLP)
Tag
Environmental
Operating Temperature
-10°C (+14°F) to
+55°C (+131°F)
Storage Temperature
-20°C (-4°F) to
+60°C (+140°F)
Maximum Humidity 95% non-condensing
EMC Environment
Residential
Commercial
Light Industrial
Industrial
Physical
Dimensions (W x H x D) 145mm x 115mm x 30mm
Packed Weight 260g Approx.
Zone Expanders
Electrical
Operating Voltage 9 - 13.7VDC
ACE Type B
Current Consumption 4XP 8XP
Quiescent
Alarm (Nothing Connected)
65mA
65mA
Data Network
4-wire standard 7/0.2 alarm cable
up to 500m Star, Daisy Chain or
any combination of the two
Zones
8XP
60IXD
8 DP or EOL zones
60 iD zones (2 loops)
EOL Resistor Values
EOL Resistor
Contact Resistor
Fault Resistor
0 - 1k
1k1 to 4k
4k1 to 5k6
5k7 to 8k
8k1 to 20k (30k)
21k+ (30k+)
(Alternatives Available)
2k2 (3k3)
4k7 (3k3)
2k2
Zone Short
Zone Secure
Zone Fault
Zone Active
Zone Mask
Zone Tamper
Outputs
Outputs 1 & 2 (4XP)
Outputs 1 - 8 (8XP)
100mA switched to 0V
100mA switched to 0V
Speaker Output (4XP & 8XP)
Minimum load 8Ω
Environmental
Operating Temperature
-10°C (+14°F) to
+55°C (+131°F)
Storage Temperature
-20°C (-4°F) to
+60°C (+140°F)
Maximum Humidity 95% non-condensing
EMC Environment Residential
Commercial
Light Industrial
Industrial
Physical
Dimensions (W x H x D)
170mm x 140mm x 35mm
Packed Weight 200g Approx.
Output Expanders
Electrical
Operating Voltage 9 - 13.7VDC
ACE Type B
Current Consumption
Quiescent
Alarm (Nothing Connected)
65mA
65mA
Network 4-wire standard 7/0.2 alarm cable up
to 250m Star, Daisy Chain or any
combination of the two
Bank 1 Outputs
Outputs 1 to 8
Bank 2 Outputs
Outputs 1 to 8
100mA switched to 0V
100mA switched to 0V
Environmental
Operating Temperature
-10°C (+14°F) to
+55°C (+131°F)
Storage Temperature
-20°C (-4°F) to
+60°C (+140°F)
Maximum Humidity 95% non-condensing
EMC Environment
Residential
Commercial
Light Industrial
Industrial
Physical
Dimensions (W x H x D) 170mm x 140mm x 35mm
Packed Weight 200g Approx.
