Premier Elite 24,24-W, 48,48-W, 88, 168 & 640 Installation Manual Standards
INS176-9 125
6. Specifications Control Panels
Identifying the Control Panel
Type Code Description
AEO Premier 24
AEJ Premier 48
AFG Premier 48-W 868MHz
AEK Premier 88
AEL Premier 168
AEZ Premier 640
Premier Elite 24 (Polymer)
Current
Maximum Current Available
0.3A charge 1.1A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h
1 x 7Ah 0.3A 0.48A
Standby and Recharge Times
EN50131-1 Grade 1 Grade 2
Maximum Recharge Time 72 Hrs 72 Hrs
PD6662 Grade 1 Grade 2
Standby Period 12 Hrs 12 Hrs
Maximum Recharge Time 72 Hrs 72 Hrs
Power Supply Type A
Rated Input: 100V - 240V @ 50/60Hz; 1A
Rated Output Current @ 55°C:: 1.5A MAX
Rated Output Voltage: 13.&Vdc +/- 2%
Mains Terminal Block Fuse: 250Vac; 3-3.15A Slow/Medium Blow
Maximum rating of each power output (note that these are not considered to be
"independent power outputs" according to EN50131-6
Aux 12V
Bell/Strobe
Network 1
Battery
DC+/DC-
1.0A
1.0A
1.0A
1.6A
1.0A
Standby Current 95mA
Output Voltage Range: 13.0V to 13.9V
Maximum Ripple Voltage: 0.5V pk-pk
Battery type: sealed lead acid, up to 7Ah, Maximum
recharge time 72h
Battery Low Voltage Signal: 9.5V
Power Output Fault signal: 10.5V (with mains present)
Deep Discharge protection: 8.1V
Over voltage protection trigger: 16V
Fuses F1 (900mA) Auxiliary 12V Power fuse
(electronic PTC)
F2 (900mA) Digicom Power (electronic
PTC)
F3 (900mA) Network 1 fuse (electronic
PTC)
F4 (900mA) Bell/Strobe fuse
(electronic PTC)
F6 (1.6 Amp) Battery fuse (electronic
PTC)
Housing 3mm Polycarbonate
Battery Compartment One 12V 7.0Ah battery
Packed Weight 1.5 Kg (Approx)
Premier Elite 24 (Metal)
Current
Current Consumption 95mA
Maximum Current Available
0.75A charge 1.0A
0.3A charge 1.9A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h 24h 30h 60h
1 x 17Ah
0.3A 1.32A 0.61A 0.47A 0.18A
0.75A 1.0A 0.61A 0.47A 0.18A
Standby and Recharge Times
EN50131-1 Grade 1 Grade 2 Grade 3
Minimum Standby Period 12h 12h 30h *
Maximum Recharge Time 72 Hrs 72 Hrs 24 Hrs
PD6662 Grade 1 Grade 2 Grade 3
Standby Period 12 Hrs 12 Hrs 24 Hrs **
Maximum Recharge Time 72 Hrs 72 Hrs 24 Hrs
*30h if MAINS FAIL is reported to ARC, otherwise 60h
**This time may be halved if mains failure is signalled to an ARC
Jumper Settings
Battery Arrangement
Recharge
Time
Battery Charge Selector
1 x 7Ah < 24Hrs 0.3 A
1 x 17Ah
< 24Hrs 0.75 A
< 72Hrs 0.3 A
Power Supply Type A
Rated Input:
Rated Output Current@40°C:
220V - 240V @50/60Hz; 1A
2.5A MAX
Rated Input:
Rated Output Current@40°C:
100VV - 120V @50/60Hz; 1A
2.3A MAX
Rated Output Voltage: 13.&Vdc +/- 2%
Mains Terminal Block Fuse: 250Vac; 3-3.15A Slow/Medium Blow
Maximum rating of each power output (note that these are not considered to be
"independent power outputs" according to EN50131-6
Aux 12V
Bell/Strobe
Network 1
Battery
DC+/DC-
1.0A
1.0A
1.0A
1.6A
1.0A
Standby Current 95mA
Maximum Ripple Voltage: 0.5V pk-pk
Battery type: sealed lead acid, up to 18Ah,
Maximum recharge time 24h (0.75A
charge rate) 72h (0.3A charge rate)
Battery Low Voltage Signal: 9.5V
Power Output Fault signal: 10.5V (with mains present)
Deep Discharge protection: 8.1V
Over voltage protection trigger: 16V
Fuses F1 (900mA) Auxiliary 12V Power fuse
(electronic PTC)
F2 (900mA) Digicom Power (electronic
PTC)
F3 (900mA) Network 1 fuse (electronic
PTC)
F4 (900mA) Bell/Strobe fuse
(electronic PTC)
F6 (1.6 Amp) Battery fuse (electronic
PTC)
Dimensions (W x H x D) 315mm x 415mm x 100mm
Battery Compartment Up tp one 18Ah battery
Packed Weight 4.5 Kg (Approx)
Premier Elite 48-W
Current
Current Consumption 150mA
Maximum Current Available
