Texecom Premier Elite 24

Specifications Premier Elite 24,24-W, 48,48-W, 88, 168 & 640 Installation Manual
126 INS176-9
0.3A charge 1.0A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h
1 x 7Ah 0.3A 0.433A
Standby and Recharge Times
EN50131-1 Grade 1 Grade 2
Minimum Standby Period
12h
12h
Maximum Recharge Time 72 Hrs 72 Hrs
PD6662 Grade 1 Grade 2
Standby Period 12 Hrs 12 Hrs
Maximum Recharge Time 72 Hrs 72 Hrs
Power Supply Type A
Rated Input: 100V - 240V @ 50/60Hz; 1A
Rated Output Current @ 55°C:: 1.5A MAX
Rated Output Voltage:
13.&Vdc +/- 2%
Mains Terminal Block Fuse: 250Vac; 3-3.15A Slow/Medium Blow
Maximum rating of each power output (note that these are not considered to be
"independent power outputs" according to EN50131-6
Aux 12V
Bell/Strobe
Network 1
Battery
DC+/DC-
1.0A
1.0A
1.0A
1.6A
1.0A
Standby Current 150mA
Output Voltage Range: 13.0V to 13.9V
Maximum Ripple Voltage: 0.5V pk-pk
Battery type:
sealed lead acid, up to 7Ah, Maximum
recharge time 72h
Battery Low Voltage Signal: 9.5V
Power Output Fault signal: 10.5V (with mains present)
Deep Discharge protection: 8.1V
Over voltage protection trigger: 16V
Fuses F6 PTC (0.9A) Auxiliary 12V Power
fuse
F4 PTC (0.9 A) Network 1 fuse
F5 PTC (0.9 A) Bell/Strobe fuse
Housing 3mm Polycarbonate
Dimensions (W x H x D) 305mm x 263mm x 98mm
Battery Compartment One 12V 7.0Ah battery
Packed Weight 1.7 Kg (Approx)
Premier Elite 48/88/168
Current
Current Consumption 125mA
Maximum Current Available
0.75A charge 1.0A
0.3A charge 1.9A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h 24h 30h 60h
1 x 7Ah 0.3A 0.458A 0.166A 0.108A
1 x 17Ah
0.3A 1.29A 0.583A 0.441A 0.158A
0.75A 1.0A 0.583A 0.441A 0.1588A
Standby and Recharge Times
EN50131-1 Grade 1 Grade 2 Grade 3
Minimum Standby Period 12h 12h 30h *
Maximum Recharge Time 72 Hrs 72 Hrs 24 Hrs
PD6662 Grade 1 Grade 2 Grade 3
Standby Period 12 Hrs 12 Hrs 24 Hrs **
Maximum Recharge Time
72 Hrs
72 Hrs
24 Hrs
*30h if MAINS FAIL is reported to ARC, otherwise 60h
**This time may be halved if mains failure is signalled to an ARC
Jumper Settings
Battery Arrangement
Recharge
Time
Battery Charge Selector
1 x 7Ah < 24Hrs 0.3 A
1 x 17Ah
< 24Hrs 0.75 A
< 72Hrs 0.3 A
Power Supply
Type A
Rated Input:
Rated Output Current@40°C:
220V - 240V @50/60Hz; 1A
2.5A MAX
Rated Input:
Rated Output Current@40°C:
100VV - 120V @50/60Hz; 1A
2.3A MAX
Rated Output Voltage: 13.&Vdc +/- 2%
Mains Terminal Block Fuse: 250Vac; 3-3.15A Slow/Medium Blow
Maximum rating of each power output (note that these are not considered to be
"independent power outputs" according to EN50131-6
Aux 12V
Bell/Strobe
Network 1 & 2
Battery
DC+/DC-
1.0A
1.0A
1.0A
1.6A
1.0A
Standby Current 125mA
Output Voltage Range: 13.0V to 13.9V
Maximum Ripple Voltage:
0.5V pk-pk
Battery type: sealed lead acid, up to 18Ah,
Maximum recharge time 72h
Battery Low Voltage Signal: 9.5V
Power Output Fault signal: 10.5V (with mains present)
Deep Discharge protection: 8.1V
Over voltage protection trigger: 16V
Fuses F1 (1Amp) Auxiliary 12V Power fuse
F2 (1.6 Amp) Battery fuse (electronic
PTC)
F3 (1 Amp) Network 1 fuse
F4 (1 Amp) Bell/Strobe fuse
F5 (1 Amp) Network 2 fuse (168 only)
Housing
1mm Mild Steel
Dimensions (W x H x D) 315mm x 415mm x 100mm
Battery Compartment Up tp one 18Ah battery
Packed Weight 4.5 Kg (Approx)
Premier Elite 640
Current
Current Consumption 125mA
Maximum Current Available
0.75A charge
1.0A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h 24h 30h 60h
1 x 17Ah 0.75A 1.0A 0.558A 0.416A 0.133A
Standby and Recharge Times
EN50131-1 Grade 1 Grade 2 Grade 3
Minimum Standby Period 12h 12h 30h *
Maximum Recharge Time 72 Hrs 72 Hrs 24 Hrs
PD6662 Grade 1 Grade 2 Grade 3
Standby Period 12 Hrs 12 Hrs 24 Hrs **
Maximum Recharge Time 72 Hrs 72 Hrs 24 Hrs
*30h if MAINS FAIL is reported to ARC, otherwise 60h
**This time may be halved if mains failure is signalled to an ARC
Power Supply Type A
Rated Input:
Rated Output Current@40°C:
220V - 240V @50/60Hz; 1A
2.5A MAX
Rated Input:
Rated Output Current@40°C:
100VV - 120V @50/60Hz; 1A
2.3A MAX
Rated Output Voltage: 13.&Vdc +/- 2%
Mains Terminal Block Fuse: 250Vac; 3-3.15A Slow/Medium Blow
Maximum rating of each power output (note that these are not considered to be
"independent power outputs" according to EN50131-6
Aux 12V
Bell/Strobe
Network 1 & 2
Battery
DC+/DC-
1.0A
1.0A
1.0A
1.6A
1.0A
Standby Current 150mA
Output Voltage Range: 13.0V to 13.9V
