Texecom Premier Elite 24

System Overview Premier Elite 24,24-W, 48,48-W, 88, 168 & 640 Installation Manual
4 INS176-9
1. System Overview
System Architecture
8 Programmable
10 0mA O u tp uts
Bell Ta mper Input
Auxiliary Ta mper Input
5 Programmable
A & 1 R elay)
( on ly)
O ut pu ts
(4 x 500m
Premier 88,168 & 640
Premier
24/48/88/168/640*
Pre mi er LC D/LC DP
Pre mie r LC DL/LC DLP
4 Wire Da ta Net wo rk 1
16 Programmable
10 0mA O u tp uts
4 ke ypads
4 K ey pa ds ( )
8 K ey pa ds ( )
16 K ey pa ds ( )
P remi er 48
P remi er 88
P remi er 16 8
()
64 K ey pa ds ( )
Pre mier 24
P remi er 64 0
Premier O P16
1 Output Module
2 Output Modules ( )
4 Output Modules ( )
8 Output Modules ( )
32 Output Modules
P remier 48
P remier 88
Pre mier 168
()
()
Pre mier 24
P remier 640
8 Z one Inputs
Alarm Receiving
Centre
Mod em
P C and M odem for
R emote Upload/Download
PC-Com
P C and for
Local Uploa d/Download
PC - C om
P lu g o n D igimo de m
(Co m300, Co m2400)
GS M Mo dule
We bwa y On e, E mizo n
or C hiro n Iris
2 Z on e
In pu ts
1Programmable
100 mA Ou tpu t
2 Z on e
In pu ts
1Programmable
100 mA Ou tpu t
S peaker
Output
A dd itio na l
4 W ire Da ta Ne two rk
S pe aker Outp ut
8 Z one Inp uts
Auxiliary Inp ut
P rem ie r 8XP
8 Programmable
10 0mA O u tp uts
2 E xpande rs
4 E xpand e rs ( )
8 E xpand e rs ( )
1 6 E xpand e rs ( )
Pre mier 48
Pre mier 88
Pre mier 168
()
6 4 E xpand e rs ( )
Pre mier 24
P remier 640
Wire as Network 1
8 to 24 zones ( )
8 to 4 8 Zon e s ( )
8 to 8 8 Zon e s ( )
8 to 16 8 Zon e s ( )
Pre mier 24
Pre mier 48
Pre mier 88
Pre mier 168
0 to 64 0 Zon e s ( )Pre mier 640
B e ll/S trob e O u tpu ts
* No Onboard Zones
Control Panel
Premier Elite 24
• 8 fully programmable Double Pole or End Of Line zones
• Expandable to 24 zones via keypads and zone expanders
• 1 x 4-wire data network (standard 7/0.2 alarm cable)
• Up to 4 keypads and 2 zone expanders
• Up to 1 output module
• 2 independent areas each with 3 part arms
• 2 area arm suites
• 25 programmable User codes
• 500 Event Log (time & date stamped)
• 1 programmable panel outputs (1 x 100mA )
• 1.5 Amp power supply (plastic Case)
Premier Elite 48
• 8 fully programmable Double Pole or End Of Line zones
• Expandable to 48 zones via keypads and zone expanders
• 1 x 4-wire data network (standard 7/0.2 alarm cable)
• Up to 4 keypads and 4 zone expanders
• Up to 2 output modules
• 4 independent areas each with 3 part arms
• 4 area arm suites
• 50 programmable User codes
• 500 Event Log (time & date stamped)
• 2 programmable panel outputs (2 x 1A )
• 2.5 Amp power supply
Premier Elite 24-W & 48-W
• 4 Onboard Zones
• 8 wireless device Ricochet™ enabled receiver onboard (24-W)
• 32 wireless device Ricochet™ enabled receiver onboard (48-W)
• Expandable to 24/48 zones via keypads and zone expanders
• 1 x 4-wire data network (standard 7/0.2 alarm cable)
• Up to 4 keypads and 2/3 zone expanders
• Up to 2 output modules
• 2 or 4 independent areas each with 3 part arms
• 2 or 4 area arm suites
• 25 or 50 programmable User codes
• 500 Event Log (time & date stamped)
• 1 or 2 programmable panel outputs (2 x 500mA )
• 1.5 Amp power supply
Premier Elite 88
• 8 fully programmable Double Pole or End Of Line zones
• Expandable to 88 zones via keypads and zone expanders
• 1 x 4-wire data network (standard 7/0.2 alarm cable)
• Up to 8 keypads and 8 zone expanders
• Up to 4 output modules
• 8 independent areas each with 3 part arms
• 8 area arm suites
• 100 programmable User codes
• 1000 Event Log (time & date stamped)
• 5 programmable panel outputs (4 x 1A & 3A relay)
