Texecom Premier Elite 24

Premier Elite 24,24-W, 48,48-W, 88, 168 & 640 Installation Manual Standards
INS176-9 127
Maximum Ripple Voltage: 0.5V pk-pk
Battery type: sealed lead acid, up to 18Ah,
Maximum recharge time 72h
Battery Low Voltage Signal: 9.5V
Power Output Fault signal:
10.5V (with mains present)
Deep Discharge protection: 8.1V
Over voltage protection trigger: 16V
Fuses (Electronic PTC)
F3 (1600 mA) Battery
F4 (250mA) Speaker
F5 (900mA) Network 1
F6 (900mA) Bell/Strobe
F7 (900mA) Network 2
F8 (900mA) Network 3
F9 (900mA) Network 4
F10 (900mA) Network 5
F11 (900mA) Network 6
F12 (900mA) Network 7
F13 (900mA) Network 8
F14 (900mA) Auxiliary 12V
Housing
1mm Mild Steel
Dimensions (W x H x D) 315mm x 415mm x 100mm
Battery Compartment Up tp one 18Ah battery
Packed Weight 4.5 Kg (Approx)
General (All Models)
Data Network 4-wire standard 7/0.2 alarm
cable up to 500m Star, Daisy
Chain or any combination of the
two
Remote Keypads
24 &48 & 48-W
88
168
640
Up to 4
Up to 8
Up to 16
Up to 64
Expanders
24
48 & 48-W
88
168
640
Up to 2
Up to 4
Up to 8
Up to 16
Up to 64
Output Modules
24
48 & 48-W
88
168
640
1
Up to 2
Up to 4
Up to 8
Up to 32
Zones
24
48
48-W
88
168
640
8 expandable to 24
8 expandable to 48
4 expandable to 48
8 expandable to 88
8 expandable to 168
0 expandable to 640-
EOL Resistor Values
EOL Resistor
Contact Resistor
Fault Resistor
0 - 1k
1k1 to 4k
4k1 to 5k6
5k7 to 8k
8k1 to 20k (30k)
21k+ (30k+)
(Alternatives Available)
2k2 (3k3)
4k7 (3k3)
2k2
Zone Short
Zone Secure
Zone Fault
Zone Active
Zone Mask
Zone Tamper
Digicom Outputs
Outputs 1 to 8
100mA switched to 0V
Panel Outputs
PG1 (24 only)
Outputs 1 & 2 (48/88/168)
Outputs 3 & 4 (88/168)
Output 5 (88/168)
100mA -ve
500mA switched to 0V
500mA switched to 12V
3 Amp Relay
Siren Outputs
Bell Trigger
Strobe Trigger
1A switched to 0V
1A switched to 0V
Speaker Output
Minimum load 8Ω
Environmental (All Models)
Operating Temperature
-10°C to
+40°C
Storage Temperature
-20°C o
+60°C
Maximum Humidity 95% non-condensing
EMC Environment
Residential
Commercial
Light Industrial
Industrial
Inhibit Functions
For Alarms and Tamper is controlled by the Swinger shutdown
counter which is programmable and is defaulted to 3.Please see
page 46 and 69.
Minimum Logical Keys
10,000 for 4 digit code*
100,000 for 5 digit code*
1,000,000 for 6 digit code*
The number of disallowed codes = 0*
 User codes must be programmed as a 6 digit code to
comply with INCERT.
 Dependant on the use of the Black Listed codes function
available via Wintex, a maximum of 16 codes may be Black
Listed
Calibration Checks & Adjustments
There are no calibration checks or adjustments available on the
control panel.
Signal & Message Processing Indications
First alarm indications followed by any other events during the set
period will scroll and can be controlled by the
 key on the
keypad.
Memory Support
A memory support battery is not required.
Compliance Label
If the alarm system is programmed to NOT conform with EN50131-1
or EN50131-3 or is installed to Grade 1 the compliance label MUST
be removed.
Engineer Access
Global Options/System Configuration Option 10 see page 64 set to
Engineer only EN50131 and User + Engineer for PD6662.
Microprocessor Identification
Premier Elite 24/48/88/168 24LC256I/P
Premier Elite 640
25LC1024I/P
