System Outputs Premier Elite 24,24-W, 48,48-W, 88, 168 & 640 Installation Manual
80 INS176-9
35 - 24Hr Zones Omit
This output type activates when a zone programmed as ‘24Hr Audible’
or ‘24Hr Silent’ (with the ‘Omit’ attribute) is omitted by the user, and
deactivates when the zone is reinstated.
36 - Reset Required
This output type activates when the selected area requires a reset
following an alarm, and deactivates when the alarm is reset.
37 - Door Strike
This output type activates for the 4 seconds when a User code with the
‘Door Strike’ attribute is entered for the selected area.
38 - Chime Mimic
This output type activates for 2 seconds when a zone in the selected
area with the ‘Chime’ attribute is activated.
39 - Chime Enabled
This output type activates when ‘Chime’ is enabled for the selected
area, and deactivates when ‘Chime’ is disabled for the selected area.
40 - DK First Knock
This output type activates when a zone in the selected area with the
‘Double Knock’ attribute is activated for the first time, and deactivates
when the zone causes an alarm or the ‘Double Knock Delay’ timer
expires.
41 - BP First Knock
This output type activates when a zone in the selected area with the
‘Beam Pair’ attribute is activated for the first time and deactivates when
another zone with the ‘Beam Pair’ attribute, causes an alarm or the
‘Beam Pair Time’ expires.
42 - On Test
This output type activates when a zone in the selected area with the
‘Test’ attribute is placed on test and deactivates when the ‘Soak Test
Time’ expires.
43 - Test Fail
This output type activates when a zone in the selected area with the ‘Test’
attribute is placed on test (and fails) and deactivates when an Engineer
code is entered or the ‘Soak Test Time’ expires.
44 - Internal Alarm
This output type activates when an Internal alarm occurs in the selected
area, and deactivates when the alarm is cancelled.
45 - Auto Arming
This output type activates when the selected area ‘Auto Arms’, and
deactivates when the selected area is disarmed.
46 - Time Arming
This output type activates for 5 minutes prior to the selected area
being armed using the ‘Control Timers’.
47 - 1
st
Code Entered
This output type activates for 30 seconds when a User code with the
‘Dual Code’ attribute is entered for the selected area.
48 - 2
nd
Code Entered
This output type activates for 30 seconds when two User codes with
the ‘Dual Code’ attribute are entered for the selected area.
49 - Area Secured
This output type activates whenever a ‘Security Key’ zone type is
used to lock keypads out and deactivates when the keypads are
unlocked again.
50 - Part Armed 1
This output type activates when a Part Arm 1 is selected for the
selected area and deactivates when part arm 1 is disarmed.
51 - Part Armed 2
This output type activates when a Part Arm 2 is selected for the
selected area and deactivates when part arm 2 is disarmed.
52 - Part Armed 3
This output type activates when a Part Arm 3 is selected for the
selected area and deactivates when part arm 3 is disarmed.
53 - Custom Alarm
This output type activates when any ‘Custom’ zone type causes an
alarm in the selected area and deactivates when a valid user code is
entered.
54 - Zone Warning
This output type activates when ‘Custom’ zone type in the selected
area with the ‘Warning Req’ attribute (see page 52 for details) is
activated for the duration of the ‘Warning Delay’ timer (see page 63
for details) and deactivates when the zone activity is cleared.
55 - Arm Fail Warning
This output type activates when the selected area fails to arm after a
period of time (controlled by the area exit time) when using
‘Entry/Exit’ or ‘Exit Term.’ arming and deactivates when the area arms.
56 - Forced Entry
This output type activates for the duration of the ‘Forced Entry’ timer
(see page 63 for details) when any ‘Guard’ or ‘Custom’ zone with the
‘Guard’ attribute is activated (see page 51 for details),.
57 - Zones Locked Out
This output type activates when any zone is locked out following an
Intruder Alarm activation and deactivates when all zones are clear
and reinstated.
58 - All Areas Armed
This output type activates when all of the selected areas are armed
and deactivates when any one of those areas is disarmed.
59 - Time Arm Disabled
This output type activates when the timed arming procedure is
disabled (see page 52 for details) and deactivates when timed
arming is reinstated.
60 - Armed/Alarm
This output type activates when the selected area is armed and
deactivates when the selected area is disarmed
This output type also pulses when an Intruder alarm occurs in the selected
area, and deactivates when the selected area is disarmed.
61 - Intruder Alarm
This output type activates when an Intruder alarm occurs, and
deactivates when the Intruder alarm is cancelled.
Tamper alarms will not activate this output
62 - Speaker Mimic
This output type activates whenever the internal speaker output is on,
and deactivates when the speaker output is off.
63 - Full Armed/Exit
This output type activates when the selected area is in the full arm exit
mode and then arms and deactivates when the area is disarmed.
64 - Detector Fault
This output type activates when a detector fault occurs and
deactivates when the fault is reset.
65 - Detector Masked
This output type activates when a detector mask occurs and
deactivates when the mask is reset.
66 - Fault Present
This output type activates when a general fault occurs i.e. Line Fault,
AC Mains Fail, Detector Fault etc. and deactivates when the fault is
cleared.
67 - LED Control
This output type is always activate and deactivates when a User or
Engineers code is entered to gain access to a menu. The output
activates again 30 seconds after the user/engineer exits the menu.
This output type is for use with detectors that require 0V applied to
disable their LED’s.
68 - Full Arm Entry
This output type activates when the entry mode is started and
deactivates when the entry mode finishes whenever the system in
Full Armed.
69 – Fire Sounder
This output type activates when a Zone programmed as ‘Fire’, or a
Keypad Fire (4&6) causes a Fire Alarm in the selected area and
deactivates when the alarm is reset.
