Premier Elite 24,24-W, 48,48-W, 88, 168 & 640 Installation Manual UDL & Digi Options
INS176-9 93
The following options are used when a Paknet Radio-Pad is
connected to the control panel in order to achieve DUAL
SIGNALLING to an Alarm Receiving Centre, when a MODEM
(External PC or Com2400) is used to connect to the control panel or
send SMS messages to mobile phones, when an AV Module is
connected to the control panel in order to achieve AUDIO
VERIFICATION to an Alarm Receiving Centre or when a TCP/IP
Module is connected for communications over a
Broadband/ADSL/DSL Line.
Setup Radio-Pad
Pad ARC 1 Pri No
This is the first number that is used by the Radio-Pad for reporting
events to ARC 1.
Pad ARC 1 Sec No
This is the second number that is used by the Radio-Pad for
reporting events to ARC 1.
Pad ARC 1 Prefix
This number will prefix the account number for ARC 1.
Pad ARC 2 Pri No
This is the first number that is used by the Radio-Pad for reporting
events to ARC 2.
Pad ARC 2 Sec No
This is the second number that is used by the Radio-Pad for
reporting events to ARC 2.
Pad ARC 2 Prefix
This number will prefix the account number for ARC 2.
Pad ARC 3 Pri No
This is the first number that is used by the Radio-Pad for reporting
events to ARC 3.
Pad ARC 3 Sec No
This is the second number that is used by the Radio-Pad for
reporting events to ARC 3.
Pad ARC 3 Prefix
This number will prefix the account number for ARC 3.
Radio-Pad Attempts
This is the number of times the Radio-Pad will try to dial the Alarm
Receiving Centre telephone number before giving up.
The number of dialling attempts is limited to 9. If this value is
set to 0, the Radio-Pad will never dial out.
Setup AV Module
AV No. 1>
This is the first number that is dialled by the AV Module.
AV No. 3>
This is the second number that is dialled by the AV Module.
AV No. 3>
This is the third number that is dialled by the AV Module.
AV Dial Attempts
This is how many times the AV Module will attempt to dial before
giving up.
The number of dialling attempts is limited to 9. If this value is
set to 0, the AV Module will never dial out.
AV Re-Dial Delay
This is the amount of delay that the AV Module uses between re-
dialling telephone numbers.
Setup IP Module
ComIP Address
This is the IP Address of the IP Module.
ComIP Port
This is the Port number of the IP Module.
ComIP Gateway
This is the Gateway IP Address that the IP Module communicates
through.
ComIP Mask
This is the Subnet Mask number for the IP Module.
Polling/SMG Address
This is the IP address of a dedicated Polling or SMG Server that the
IP Module might need to connect to.
Name/SMG Port
This is a descriptive name for the IP Module or SMG Port and might
be used for authentication purposes.
Chiron Iris GPRS Data
Access Pnt Name
This is the GPRS Access point Name provided by Chiron
User Name
This is the APN User Name provided by Chiron
Password
This is the APN password provided by Chiron.
SMS Centres
SMS Centre Pri.
This is the first SMS centre telephone number that is used by for
sending SMS to mobile phones. (Default = 07785499993).
SMS Centre Sec.
This is the second SMS centre telephone number that is used by for
sending SMS to mobile phones. (Default = 07860980480)
Modem
Modem Setup Stg.
If a standard PC modem is connected to Com1 or Com2, it may
require a configuration string to make it work properly (please refer
to instruction manual of modem being used for details of required
AT commands).
The Setup string is programmed the same way that TEXT
would be programmed and has a maximum length of 16
characters.
The setup string does NOT require AT to be entered at the
beginning as this is done automatically.
Modem Speed
This option allows the speed of a standard PC modem connected to
Com1 or Com2 to be adjusted.
Radio-Pad Info
Pad Serial No.
This screen displays the Serial number of the Radio-Pad that is
connected.
Pad NUA
This screen displays the NUA number of the Radio-Pad that is
connected.
Last Call From
This screen displays the NUA number of the last Radio-Pad that
communicated with the Radio-Pad that is connected to the control
panel.
FSS:??? (>=004), Forward Signal Strength
RSS:??? (>=050), Reverse Signal Strength
This screen displays the Radio-Pad Forward (FSS) and Reverse
(RSS) Signal Strength of the Radio-Pad that is connected to the
control panel.
The FSS value should be greater than or equal to 4 and the RSS
value should be greater than or equal to 50.
To Next Page
