EX-TRACK
®
Operator Manual, Revision T-1 25
Torch lifting mechanism: comprises of lifting motor, lifting screw, guide shaft and fittings.
Torch mounting assembly: comprises of connector, clamp and manual lifting wheel. The torch
height and vertical positioning can be adjusted manually, so as to ensure that cut is square. For edge
beveling, rotate the torch along the longitudinal or transverse direction to perform an angled cut.
3.5. Gas supply
The system uses oxygen and fuel gas hoses for the delivery of gases to the torch; Gas ignition and
flame adjustment are performed manually.
DO NOT USE ACETYLENE FUEL GAS WITH THIS SYSTEM!
See Section 5.2 for operation.
