3
Learning Center
Measure a Sample Using a Cuvette
Thermo Scientific NanoDrop One User Guide 201
Best practices for cuvette measurements
To measure a sample using a cuvette
The instrument arm can be up or
down for cuvette measurements.
Use 10 mm, 5 mm, 2 mm or 1 mm
cuvettes up to 48 mm tall.
Clean and dry cuvette after each
measurement.
Use cuvettes that are free of scratches
and avoid fingerprints which may
affect results.
Use quartz cuvettes or UV-grade
plastic cuvettes to measure samples
with analysis wavelengths in the
UV range (<340 nm).
Micro, semi-micro, and ultra-micro
cuvettes should be masked.
Fill cuvettes with enough blanking or
sample solution to cover instrument
optical path (2 mm sample beam is
8.5 mm above cuvette bottom).
Lift instrument arm and make sure
cuvette holder is free of debris.
When inserting quartz or masked
plastic cuvettes, align cuvette light path
with instrument light path.
Instrument light path
Cuvette holder
NOTICE
To prevent damage from spills, keep containers of liquids away from the instrument.
Do not use a squirt or spray bottle on or near the instrument as liquids will flow into
the instrument and may cause permanent damage.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Thermo NanoDrop One and is the answer not in the manual?

Thermo NanoDrop One Specifications

General IconGeneral
Wavelength Range190-850 nm
Pathlength1 mm and 0.2 mm (Auto-ranging)
Detection Limit2 ng/µL (dsDNA)
Light SourceXenon flash lamp
Maximum Concentration15, 000 ng/µL (dsDNA)
Detector2048-element linear silicon CCD array
Measurement Time< 5 seconds
Weight2.0 kg (4.4 lbs)
Nucleic Acid QuantitationYes
Protein QuantitationYes
Display7-inch capacitive touch screen
Sample Volume1-2 μL
Absorbance Precision±0.002 A
Operating Voltage100 to 240 V AC
Dimensions (W x D x H)20 cm x 25 cm x 15 cm (8 in. x 10 in. x 6 in.)
SoftwareThermo Scientific™ software
ConnectivityUSB, Ethernet, Wi-Fi
Operating Temperature15 - 35°C
Dimensions20 cm x 25 cm x 15 cm (8 in. x 10 in. x 6 in.)
Absorbance Range0 - 550 A (10 mm equivalent)
