Thermo NanoDrop One User Manual

Thermo Scientific NanoDrop One User Guide 1
1
About the NanoDrop One Spectrophotometer
The Thermo Scientific™ NanoDrop™ One is a compact,
stand-alone UV-Visible spectrophotometer developed for
micro-volume analysis of purified nucleic acids and a wide
variety of proteins. The patented sample retention system
enables the measurement of highly concentrated samples
without the need for dilutions.
The NanoDrop One system comes with preloaded software and
a touchscreen display. The instrument can be connected to an
optional USB label printer.
NOTICE Before operating a NanoDrop One instrument, please read the safety and
operating precautions and then follow their recommendations when using the instrument.
Instrument Models and Features
There are two models available for the
NanoDrop One spectrophotometer...
Register Your Instrument
Register your instrument to receive e-mail updates on
software and...
Optional Accessories
A number of accessories are available for the
NanoDrop One instruments...
Update Software
Quickly and easily download the latest
NanoDrop One software...

Thermo NanoDrop One Specifications

General

Wavelength Range	190-850 nm
Pathlength	1 mm and 0.2 mm (Auto-ranging)
Detection Limit	2 ng/µL (dsDNA)
Light Source	Xenon flash lamp
Maximum Concentration	15, 000 ng/µL (dsDNA)
Detector	2048-element linear silicon CCD array
Measurement Time	< 5 seconds
Weight	2.0 kg (4.4 lbs)
Nucleic Acid Quantitation	Yes
Protein Quantitation	Yes
Display	7-inch capacitive touch screen
Sample Volume	1-2 μL
Absorbance Precision	±0.002 A
Operating Voltage	100 to 240 V AC
Dimensions (W x D x H)	20 cm x 25 cm x 15 cm (8 in. x 10 in. x 6 in.)
Software	Thermo Scientific™ software
Connectivity	USB, Ethernet, Wi-Fi
Operating Temperature	15 - 35°C
Dimensions	20 cm x 25 cm x 15 cm (8 in. x 10 in. x 6 in.)
Absorbance Range	0 - 550 A (10 mm equivalent)
