Figure 2 Instrument deck
1
Tip box holders (2); tip box installed in left holder
2
OpenArray
™
Plate holders (4)
3
Sample plate holder with sample plate installed
4
Waste bin
1
2
3
Figure 3 Left side panel
1
Power switch
2
Power cord outlet
3
USB port
