Topcon DL-501 User Manual

65
14. CALCULATION FUNCTIONS
 Double-run Discrepancy
("Fixed pt rec" = "Yes")
Press [NEXT]/[PREV] to display results for
the next/previous measurement point.

• Adjustment values displayed and recorded
are those averaged for the go leg only.
Applied adjustment value = total
discrep
ancy for both the go and return legs
÷ 2.
Press [LIST] in the second page to display a
list of all measurement points used to
calculate misclosure.
Align the cursor with a
point id and press {} to display adjustment
results for that point.
•Press [TOP] to move to the first point id on
the first page.
•Press [LAST] to move to the last point id on
the last page.
Go
Fixed pt No.0001
Pt.id FS0001
Adj.value -0.52mm
Z 1223.44270m
REC
P1
IS
NEXT
PREV
Go
Fixed pt No.0001
Pt.id FS0001
Adj.value -0.52mm
Z 1223.44270m
P2
LIST
BS0000
FS0001
FS0002
FS0003
LAST
TOP
