14. CALCULATION FUNCTIONS
66
 Link Closure/Loop Closure
("Fixed pt rec" = "Yes")
Press [NEXT]/[PREV] to display results for
the next/previous measurement point.

• Measurement points are displayed in the
same order in which they occur on the link/
loop.
• When two routes in a link/loop have been
connected end bench mark to end bench
mark, points in the latter route will be
displayed from end bench mark to start
bench mark.
• Adjustment values are determined so as to
reduce misclosure to 0. For example,
when misclosure is 6mm, the adjustment
value will be -6mm.
Press [LIST] in the second page to display a
list of all measurement points used to
calculate misclosure.
Align the cursor with a
route and press {} to display a list of
measurement points in that route.
•Press [TOP] to move to the first route on the
first page.
• Press [LAST] to move to the last route on the
last page.
Route001
Pt.id RT001FS0010
Adj.value -0.52mm
Z 1223.44270m
REC
P1
IS
NEXT
PREV
Route002
Pt.id RT002BS0000
Adj.value -1.06mm
Z 1221.34754m
REC
P1
IS
NEXT
PREV
Route 1
Route 2
All points in route 1 displayed
All points in route 2 displayed
in order
Route001
Pt.id RT001BS0000
Adj.value 0.00mm
Z 1227.61832m
REC
P1
IS
NEXT
in order
Route002
Pt.id RT002FS0003
Adj.value -1.08mm
Z 1220.68226m
REC
P1
IS
NEXT
PREV
Points in subsequent routes
displayed in the same way.
001 Route-01
002 Route-02
003 Route-03
004 Route-04
LAST
TOP
DL-501_E.book 66 ページ ２０１５年９月１７日 木曜日 午後１時２１分
