GR-5 Configuration
GR-5 Operator’s Manual
3-34
4. On the Connection Parameters dialog box, select the following
parameters (Table 3-2) and click Connect (Figure 3-29).
Figure 3-30. Connection Parameters
Table 3-2. Connection Parameters
Parameter RS232 or Bluetooth USB
Connection
Mode
Select Direct.
Port Select the port connecting the
computer and receiver
(typically COM1, COM2 for
RS232 and COM3, COM4
for Bluetooth)
Select USB
Baud Rate Select the communication rate
between the receiver and the
computer (usually 115200).
n/a
Rec ID n/a Select the receiver’s
identification number.
USB
RS232 or Bluetooth
