Configuring the Receiver Using TRU
P/N 7010-1004
3-23
8. Click the Tracking icon, and set the antenna type used with the
connected receiver (Figure 3-19).
Figure 3-19. Set Antenna Usage
9. Click the Observation tab, and set the Elevation mask to 15
degrees for satellites tracking and position computation
(Figure 3-20), also the PDOP mask for position computation,
then click OK.
Figure 3-20. Configure Receiver Positioning – Elevation Mask
10. Click the Advanced tab. Set the following parameters, and click
OK (Figure 3-21 on page 3-24).
