1-2
1 NOMENCLATURE AND FUNCTIONS
Telescope focusing knob
Telescope grip
Telescope eyepiece
Plate level
Circular level
Horizontal
motion clamp
Horizontal
tangent screw *1)
Instrument
center mark
Battery locking lever
Battery BT-50Q
Adjusting screw
for circular level
Tr ibrach fixing lever
GTS-601/602:
2speed way
GTS-603/605:
1speed way
GTS-601/602/603/605
Power switch
*1) ) The speed of horizontal tangent screw will differ depend on the markets.
Printer port
(Centronics connector)
