4-6
4 PROGRAM MODE
2)Without prism height input.
Horizontal distance (HD) between the
instrument and prism will be shown.
6 Press [F6](SET) key.
The prism position will be decided. *1)
[F6]
7 Collimate target K.
Vertical distance (VD) will be shown. *2)
Collimate
K
*1)To return to procedure
3, press [F2](P.h) key.
To return to procedure
4, press [F3](HD) key.
*2)To return to main menu, press [F1](EXIT) key.
Operating procedure Operation Display
1 Press [F3](REM) key.
[F3]
2 Press [F2](NO) key.
[F2]
3 Collimate prism.
4 Press [F1](MEAS) key.
Measuring starts.
Collimate
P
[F1]
Horizontal distance (HD) between the
instrument and prism will be shown.
REM
(2)Horizontal Distance
HD : 123.456 m
MEAS SET
REM
VD : 0.234 m
EXIT P.h HD SET
REM
VD : 1.456 m
EXIT P.h HD
Programs
F1 BS p 4/8
F2 STORE p
F3 REM p
F4 MLM p MORE
REM
Prism height
1.YES
2.NO
REM
(1)Horizontal Distance
HD : m
MEAS
REM
(1)Horizontal Distance
HD* < m
MEAS SET
REM
(1)Horizontal Distance
HD : 123.456 m
MEAS SET
