4-14
4 PROGRAM MODE
Job Manager (Page 1)
In the Job Manager option there are two pages of routines for managing jobs. The first page of routines
allows the user to View Memory, Erase a Block of Data, Erase One Point, and Create Another Job. The
view memory shows all jobs in memory and allows the user to select another job if necessary. The
erase a block of points and erase one point requests the record number in order to delete points in the
job. If a new job is to be created, the last routine on page one allows the user to create the job. In order
for the job to be created, the first point number and coordinates must be entered before you exit the
routine.
Below are examples for the Options routines.
View Memory
The view memory routine shows all the jobs stored in memory. This routine also allows the user to
select another job in memory. There can be multiple pages of jobs. The [F6] (MORE) key scrolls to each
page.
Operating procedure Operation Display
1 At the Layout display, press [F4] Options.
[F4]
2 Press [F2] Job Manager.
[F2]
3 Press [F1] View Memory.
[F1]
4 The display shows all the jobs in memory on
the first page. The current job is highlighted.
The job name and number of points in the job
are also shown on the display. To view more
jobs on the second page, press [F6]. To exit
from this screen, press the (ESC) key.
LAYOUT
F1 Setting Direction Angle
F2 Setting Layout Point
F3 Coordinate data
F4 Options
Options
F1 Create or Select a Job
F2 Job Manager
Job Manager (Pg 1/2)
F1 View Memory
F2 Erase a Block of Point
F3 Erase One Point
F4 Create Another Job
↓
Select a Job (Job,# of Pts)
F1 TAC1 25 4/6
F2 TOPCON 20
F3 TAC2 10
F4 NEW 10 MORE
To Next Page
