Topcon MACHINE CONTROL AG System Five - Introduction and Setup

Chapter 1
P/N 7010-0369 www.topconpositioning.com
1-1
Introduction and
Setup
Topcon’s AG System Five™ (Figure 1-1) is a complete control
system allowing both survey and automatic operation of a scraper
or other implement. The System Five includes the Control Box,
Laser Receiver, and a TM-1 Electric Mast.
Figure 1-1. AG System Five Components
The heart of the System Five is the Control Box. The Control Box
functions can be set for particular jobs, used to take surveys, or for
automatic leveling control.
