Control Box Usage
Topcon AG System Five Operator’s Manual
2-4
Grade Adjustment Direction Arrows
The grade adjustment arrows are located at the upper left and upper
right of the grade adjustment knob.
These two arrows (Figure 2-4) light up in red to indicate the
direction you should turn the knob to reach on-grade.
Figure 2-4. Grade Adjustment Direction Arrows
Grade Adjustment Knob
The grade adjustment knob (Figure 2-5) makes measured
adjustments to elevation and slope settings, or cycles through menu
options.
Figure 2-5. Grade Adjustment Knob
Rotate Knob
C
ounterclockwise
To Reach Grade
Rotate Kno
b
Clockwise T
o
Reach Grad
e
FiveSystem
AUTO
SURVEY
SET
(MENU)
