Topcon MACHINE CONTROL AG System Five - LCD Display; Light Sensor for Grade Adjustment Arrows; Power Switch

LCD Display
P/N 7010-0369 www.topconpositioning.com
2-3
LCD Display
The LCD (Figure 2-2) allows the operator to view text and
reference settings.
Figure 2-2. LCD Display
Light Sensor for Grade Adjustment
Arrows
The light sensor monitors ambient light, increasing the intensity of
the grade arrows in bright sunlight and dimming the grade arrows
for nighttime operation.
The light sensor is located above the power switch.
Power Switch
The power switch (Figure 2-3) for the System Five Control Box
turns it on and off.
Figure 2-3. Power Switch
O
N
OF
F
