Laser Placement
P/N 7010-0369 www.topconpositioning.com
3-3
Small Project Laser Transmitter
Placement
On small projects, the laser transmitter can be placed off the
working area (Figure 3-1). The working distance from your
laser will indicate the type of project (small or large).
Figure 3-1. Laser Transmitter Placement – Small Project
1000'
