Control Box Usage
The Control Box is the operator’s interface to System Five™. The
Control Box receives signals from the sensors (such as the Laser
Receiver), and uses these signals to determine if grade or slope
corrections are necessary. If the leveling requires a change in grade
or slope, the Control Box sends a signal to the valve, raising or
lowering it to the correct height.
Control box functions provide simple ways to apply settings,
change functions, view and record elevation information, and allow
automatic or manual control.
This chapter describes:
• The buttons, knobs, and switches on the Control Box.
• How to change settings, access information, and take readings
using the various buttons, knobs, and switches.
• The menus available in the Performance Menu.
• How to access, change settings, and apply features using the
Performance Menu.
