Auto/Manual Button
P/N 7010-0369 www.topconpositioning.com
2-11
Using the Search Function
Hold the Survey/Search button for one second. The laser
receiver searches for an on-grade signal and locks on-grade.
If the laser receiver has an electric mast, press the Survey/
Search button a second time to stop the search. Press the button
a third time, and the electric mast reverses direction and
searches again.
Using the Survey Function
Hold the Survey/Search button for three seconds to enable the
Survey mode.
The laser receiver/electric mast continuously tracks the laser
beam while surveying the jobsite.
Auto/Manual Button
The auto/manual button (Figure 2-13) has three functions:
• In Control Mode, acts as an auto/manual selection button.
• In Survey Mode, acts as an on/off selection button for recording
elevation readings.
• Makes selections in the Performance Menu.
Figure 2-13. Auto/Manual Button
Using the Auto/Manual Mode
Using the Auto/Manual button, the operator can select between
Automatic Control or Manual Control.
AUTO
