20
SYSTEM DIAGRAM
Preview screen (When color photography or red-free photography is selected)
*Only in TRC-NW8
Preview screen (When FA photography is selected) *Only in TRC-NW8F
In FA photography, the preview in a small size is displayed on the Monitor screen.
(Only in the "STAND ALONE" setting)
For the "STAND ALONE" setting, contact your dealer or TOPCON (see the back cover).
In TRC-NW8F plus, the preview screen is not displayed on the color LCD monitor. It is
displayed on the monitor connected to the image filing system.
00:10:13
2009.09.15
10:40:00
R
13
10
Patient ID
Small pupil diaphragm
Fixation target position
Timer (Passage of time)
Photography date
Right/left eye
RF filter
Photographic image
Image filing system
recognition display or
printer recognition display
SD card recognition display
Recording device
recognition display
00:10:13
100
100
L
00:10:12
