SYSTEM DIAGRAM
Playback image *Only in TRC-NW8F
When the data is recorded in SD card, the FA display does not appear.
In TRC-NW8F plus, the playback image is not displayed on the color LCD monitor.
MENU screen
00:10:20
00:10:13
2009.09.15
10:40:00
00000070
20
20
R
1
Patient ID
Timer when taking a picture
Timer (Passage of time)
Fixation target position
Photography date
Right/left eye
FA or RF filter
Photographic image
Recording device
recognition display
Count of photograph
Index number
Image filing system
recognition display or
printer recognition display
MENU
ON
SHOOT
FIXATION
FLASH
MEMORY
SMALL PUPIL
OFF
FOCUS
FOCUS Icon
Item to be set Contents to be set
*The above figure shows the screen of TRC-NW8F.
