Toptech Systems MultiLoad II SCS

Chapter 13 – Custom Logic
390
Firmware Version 3/4.31.37
Parameter
Description
RCU State
A numeric value will be used to represent the current status of the
MultiLoad.
State
Numeric Value
Idle
0
Authorizing Bay
1
Program Mode
2
Diagnostic Mode
3
Authorizing Load
4
Load Authorized
5
Completing Load
6
Transaction Done
7
Transaction Cancelled
8
Pulling Transaction
9
Archiving Transaction
10
Transaction Authorized
11
RCU Not Configured
12
RCU Power Up
13
Initializing
14
No Transaction
15
Remote Authorized Preset 1
16
Remote Authorized Preset 2
17
Remote Authorized Preset 3
18
Remote Authorized Preset 4
19
Remote Authorized Preset 5
20
Remote Authorized Preset 6
21
Remote Authorized Preset 7
22
Remote Authorized Preset 8
23
Remote Authorized Preset 9
24
Remote Authorized Preset 10
25
Remote Authorized Preset 11
26
Remote Authorized Preset 12
27
