Toptech Systems MultiLoad II SCS User Manual

Chapter 13 – Custom Logic
391
Firmware Version 3/4.31.37
Parameter
Description
Card 1 Number
Gives the card number of the loader
Card 1 Facility Code
Gives the facility code of the loader
Card 2 Number
Gives the card number of the security card
Card 2 Facility Code
Gives the facility code of the security card
Security Bypass
Indicates if the Security Bypass switch is ON or OFF
Config Changed
Indicates that the MultiLoad is in Program Mode and a parameter has been
changed.
Bay Real Time (RT)
Parameter
Description
Clearing Errors
Indicates that operational alarms are being cleared. This process can be
initiated remotely or locally.
Diagnostic Mode
Indicates when the operator has entered a diagnostic screen.
All Stop
Indicates when the ALL Stop button has been pressed.
Alarm Out
Indicates when a Bay Level alarm, such as a permissive, has been
triggered.
Authorized
Indicates when a driver has successfully completed the authorization
process and is able to load.
Permissive Out
Indicates that all Bay Level permissives have been satisfied.
Permissive 0 – 7
Monitors the state of that specific permissive.
Deadman Input
Looks to the FCM port number assigned to the Deadman Input parameter
and indicates the current state.
Deadman Output
Indicates when the Deadman warning timer has expired and the Deadman
Output signal will be triggered.
Deadman Bypass
Indicates the current state of the Deadman Bypass FCM input.
Total Volume
Total Gross volume delivered of the current load for the entire Bay.
Start Transaction
Indicates the current state of the Start Transaction FCM input.
Stop Transaction
Indicates the current state of the Stop Transaction FCM input.
Total Net Volume
Total Net volume delivered of the current load for the entire Bay.
