Chapter 13 – Custom Logic
Firmware Version 3/4.31.37
Total Mass volume delivered of the current load for the entire Bay.
Indicates when a driver is authorized to use a particular preset (load arm).
Indicates when flow is active on a particular preset.
Indicates when TMS has reviewed preset quantity and product selection
information and has authorized the batch for delivery.
Indicates when a batch has been completed on a particular load arm.
Indicates that operational alarms are being cleared on a particular preset.
This process can be initiated remotely or locally.
Indicates that the batch has been archived on a particular preset. This is
done when the driver presses CLR to clear the batch, or when a load is
completed and the transaction is ended.
Indicates that a preset-level Block Valve has been commanded to open.
Looks to the Block Valve Status FCM input port and indicates the current
preset-level Block Valve status.
Indicates that a preset-level Block Valve has been commanded to close.
Indicates that the Remote Start button of a particular preset has been
pressed.
Indicates that the swing-arm of a particular preset is active (in the bay).
Indicates that the Meter Stop button of a particular preset has been
pressed.
Indicates that a preset-level alarm is active.
Indicates that a preset-level permissive is active.
Indicates that all preset-level permissives have been satisfied.
