Adding 19 kg (42 lb) W eights
1. Loosen the hardware that secures the weight-lock rod to the bumper .
g299565
Figure 19
1. W eight-lock rod
3. W eight—19 kg (42 lb)
2. Nut
2. Add the required amount of weights.
3. T ighten the weight-lock-rod hardware to secure the weight to the bumper .
Adding 6 kg (15 lb) W eights
1. Refer to your authorized T oro distributor to order the following parts:
Part Name
Quantity
Part Number
Screw (3/8 x 3-1/2 inches)
2 1 16-4701
W asher 2 125-9676
Nut (3/8 inch)
2 104-8301
2. Use the hardware to secure the weights to the bumper ( Figure 20 ).
g324822
Figure 20
1. Hardware
2. W eight—6 kg (15 lb)
25
