E6582233
J-10
10
 Torque boost parameters 2
Ti tle
Communicati
ons No.
Function Unit
Minimum
setting unit
Panel/Comm
unications
Adjustment range
Default
setting
User
setting
Reference

F480 0480 Motor specific
coefficient 7
- - - - * 1

F485 0485 Motor specific
coefficient 8
- - - -

F491 0491 Motor specific
coefficient 8A
- - - -

F495 0495 Motor specific
coefficient 9
- - - -

F499 0499 Motor specific
coefficient 10
- - - -
*1: Motor specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
 Acceleration/deceleration time parameters
Ti tle
Communicati
on No.
Function Unit
Minimum
setting unit
Panel/Comm
unication
Adjustment range
Default
setting
User
setting
Reference

F500 0500 Acceleration time
2
s 0.1/0.1 0.0-3000 10.0 6.17

F501 0501 Deceleration time
2
s 0.1/0.1 0.0-3000 10.0

F502 0502 Acceleration/decel
eration 1 pattern
- - 0: Linear
1: S-pattern 1
2: S-pattern 2
0

F503 0503 Acceleration/decel
eration 2 pattern
- - 0

F505 0505 Acceleration/decel
eration 1 & 2
switching
frequency
Hz 0.1/0.01 0.0 (disabled)
0.1-
0.0
 Protection parameters
Ti tle
Communicati
on No.
Function Unit
Minimum
setting unit
Panel/Comm
unication
Adjustment range
Default
setting
User
setting
Reference

F601 0601 Stall prevention
level 1
%
(A)
1/1
10-199，
200 (disabled)
150
6.18.2

F602 0602
Inverter trip
retention selection
- - 0: Cleared with power off
1: Retained with power off
0 6.18.3

F603 0603 Emergency stop
selection
- - 0: Coast stop
1: Slowdown stop
2: Emergency DC braking
0
6.18.4

F605 0605
Output phase
failure detection
selection
-
-
0: Disabled
1: At start-up (only one time after power
on)
2: At start-up (each time)
3,4: -
5: Detection of cutoff on output side
0
6.18.5

F607 0607 Motor 150%
overload detection
time
s 1/1 10-2400 300 3.4
6.18.1

F608 0608 Input phase failure
detection selection
- - 0: Disabled, 1: Enabled 1 6.18.6
