General product description
1.5 Technical data
Measurement:
Length: 6400 mm
Width: 1400 mm
Hight: 1400 mm
Weight: approx. 3300 kg
Hydraulic:
Working pressure: 200 bar
Nominal pressure: 250 bar
Capacity of the tank: 13 Liter
Kind of oil: HLP 46
External gear pump
Flowrate: 4,5 l/min
Duration of connection: 100%
Electrical control
Drive power: 15,0 kW
Nominal voltage: 415 V AC 3 N / PE / 50 Hz
Cable cross section of main cable: 5 x 2,5 mm²
Nominal current of main fuse: max. 25 A
